| 產(chǎn)品編號 ltem code | 外徑（D） | 厚度（H） | 內(nèi)徑（d H7） | 齒數(shù)（Z） |
| D×H×d×T | 8 | 0.15~4.0 | 3/4 | 4~20 |
| 10 | 0.15~4.0 | 4/5 | 6~24 | |
| 12 | 0.15~4.0 | 4/5/6 | 6~30 | |
| 16 | 0.15~4.0 | 5/6/8 | 6~40 | |
| 20 | 0.15~4.0 | 5/6/8 | 6~45 | |
| 25 | 0.2~5.0 | 6/8/10 | 10~56 | |
| 30 | 0.2~5.0 | 6/8/10 | 10~60 | |
| 35 | 0.2~6.0 | 8/10/12.7 | 10~60 | |
| 40 | 0.2~6.0 | 8/10/12.7 | 10~80 | |
| 45 | 0.2~8.0 | 10/12.7/16 | 10~80 | |
| 50 | 0.2~8.0 | 10/12.7/16 | 10~100 | |
| 55 | 0.2~8.0 | 12.7/16 | 24~120 | |
| 60 | 0.2~8.0 | 12.7/13/16 | 24~120 | |
| 63 | 0.2~8.0 | 12.7/13/16 | 24~120 | |
| 70 | 0.3~8.0 | 16/22/25.4 | 28~120 | |
| 75 | 0.5~8.0 | 16/22/25.4 | 30~120 | |
| D×H×d×T | 80 | 0.5~8.0 | 22/25.4 | 30~128 |
| 85 | 0.5~8.0 | 22/25.4 | 30~128 | |
| 90 | 0.5~8.0 | 22/25.4 | 30~160 | |
| 95 | 0.5~8.0 | 22/25.4 | 30~160 | |
| 100 | 0.5~8.0 | 22/25.4/27 | 30~160 | |
| 105 | 0.8~0.8 | 22/25.4/27 | 30~160 | |
| 110 | 0.8~0.8 | 22/25.4/27/32 | 30~180 | |
| 115 | 0.8~0.8 | 22/25.4/27/32 | 30~180 | |
| 120 | 1.0~10.0 | 22/25.4/27/32 | 30~240 | |
| 125 | 1.0~10.0 | 22/25.4/27 | 30~240 | |
| 130 | 1.0~10.0 | 22/25.4/27/32 | 30~240 | |
| 150 | 1.0~10.0 | 22/25.4/27/32 | 40~240 | |
| 160 | 1.0~10.0 | 22/25.4/27/32 | 40~240 | |
| 180 | 1.5~12 | 25.4/27/32/40 | 60~280 | |
| 200 | 1.5~12 | 25.4/27/32/40 | 60~280 |
